Product Overview
1. Compact‑Displacement Two‑Stroke Power Unit for Light‑Duty Civil Drones
GT17‑PRO is a premium 16.91 cc two‑stroke gasoline‑powered piston‑type UAV gasoline engine, designed exclusively for lightweight civilian‑grade unmanned aircraft.
Different from large‑displacement heavy‑lift industrial drone gasoline engines, this unit targets small‑size fixed‑wing aircraft, lightweight practice‑use UAV platforms, tiny aerial‑photography drones and hobby‑level civilian flying devices. Its compact dimension and ultra‑light weight make it the ideal power component for small‑airframe projects with strict weight‑control standards.
2. Broad‑Range Rotation Speed and Excellent High‑Speed Performance
The operational speed range spans from 1700 rpm to 9500 rpm. The broad speed window covers all common flight states for small unmanned planes. When it hits the maximum rotation speed of 9500 rpm, the UAV engine outputs its peak power of 1.98 HP, providing abundant power reserve for rapid take‑off, fast cruising and sharp climbing‑up movement.
Multiple two‑blade propeller choices are supported, so operators are capable of tuning the aircraft for slower long‑time hovering or faster‑speed travelling flight.
3. Stable Ignition Assembly and Standardized Fuel Lubrication Rules
The independent ignition component weighs only 100 grams. It accepts wide‑range direct‑current power input between 6V‑14.4V, paired with a 1000‑mAh power supply unit for consistent ignition sparks throughout the whole flight.
For fuel requirements, this drone gasoline engine uses regular civilian gasoline mixed with high‑grade fully‑synthetic 2‑stroke lubrication oil. The fixed mixing proportion is 25:1. Proper oil mixing protects the internal crankshaft and moving parts from excessive abrasion during high‑speed running.
| Technical Parameter Item | Verified Standard Parameter Value |
|---|---|
| Product Model | GT17‑PRO |
| Total Displacement | 16.91 cc |
| Usable RPM Operating Range | 1700‑9500 rpm |
| Maximum Output Power | 1.98 HP @9500 rpm |
| Main Engine Net Weight | 690 g |
| Ignition Module Weight | 100 g |
| Ignition Working Power Supply | DC 6V‑14.4V, 1000mAh power source |
| Suitable Propeller Spec (Two‑Blade) | 15×10, 17×8, 16×8‑10 |
| Required Fuel Type | Regular unleaded gasoline + full‑synthetic 2‑stroke lubricant |
| Gasoline‑to‑Lubricant Mix Ratio | 25:1 |
| Engine Type | Air‑Cooled 2‑Stroke Piston UAV Gasoline Engine |
| Suitable Civil‑Use Scenarios | Light‑weight fixed‑wing unmanned aircraft, small‑size aerial‑survey drone, hobby‑grade civilian flying machine, compact‑scale aerial photography UAV |
Packing & Shipping
Anti‑Collision Custom Foam and Hard‑Case Packaging
Every GT17‑PRO UAV engine is wrapped with shock‑absorbing foam around the cylinder, carburetor and ignition parts. The finished unit is secured inside a sturdy storage box, avoiding bump damage, dampness and dust contamination in the course of long‑distance land and cross‑border transportation. Exposed metal fittings and pipelines are covered with transparent protective film.
Full Set of Standard Matching Accessories
Each shipment contains propeller fasteners, installation gaskets, fuel‑mixing measuring cup, basic maintenance tools and an English‑language operation handbook. Optional accessories such as upgraded mufflers and replacement ignition parts are available upon buyer request.
Global Multimodal Delivery and Clearance‑Ready Documents
We cooperate with international freight providers to supply sea shipping, air courier service and land‑based door‑to‑door delivery for overseas hobby aircraft makers and small‑drone operators. Every shipment comes with packing checklist, commercial invoice and factory performance inspection papers for convenient customs clearance.
